Appendix A. Info Tables and Settings
Related Topics:
• Info Tables and Settings (p. 527)
• Common Uses of the Status Table (p. 529)
• Status Table as Debug Resource (p. 470)
Info tables and settings contain fields, settings, and information essential to setup,
programming, and debugging of many advanced CR800 systems. Info tables and
settings are numerous. Note the following:
• All info tables and settings, except a handful, are accessible through a
keyword. This discussion is organized around these keywords. Keywords
and descriptions are listed alphabetically in sub appendix Info Tables and
Settings Descriptions
(p. 536).
• Info table fields are mostly read only. Some are resettable.
• Settings are mostly read/write.
• Directories in sub appendix Info Tables and Settings Directories
(p. 529)
list several groupings of keywords. Each keyword listed in these groups
is linked to the relevant description.
• Some info tables and settings have multiple names depending on the
interface used to access them. The names are listed with the descriptions.
• No single interface accesses all info tables and settings. Interfaces used
for access include the following:
Info Tables and Settings Interfaces
Interface Location
Settings Editor
Device Configuration Utility,
LoggerNet Connect screen, PakBus
Graph
Info tables (Status, DataTableInfo,
CPIInfo, etc)
View as a data table in a numeric
monitor
Station Status
Menu item in LoggerNet
Edit Settings
Menu item in PakBusGraph software.
Keyboard/Display Settings
Menu items in Configure, Settings
status.keyword/settings.keyword
Syntax in CRBasic program
1
Information presented in Station Status is not updated automatically. Click
the Refresh button to update.
