Section 4. Quickstart
• Collect data from the CR800.
• Store the data on the PC.
4.6.5.1 Procedure: (PC200W Step 1)
1. From the PC200W Clock/Program tab, click on Connect (upper left) to
connect the CR800 to the PC. As shown in the following figure, when
connected, the Connect button changes to Disconnect.
CAUTION This procedure assumes there are no data already on the
CR800. If there are data that you want to keep on the CR800, you should
collect it before proceeding to the next step.
FIGURE 7: PC200W Main Window
4.6.5.2 Procedure: (PC200W Steps 2 to 4)
2. Click Set Clock (right pane, center) to synchronize the CR800 clock with the
computer clock.
3. Click Send Program... (right pane, bottom). A warning appears that data on
the datalogger will be erased. Click Yes. A dialog box will open. Browse
to the C:\CampbellSci\SCWin folder. Select the MyTemperature.cr8 file.
Click Open. A status bar will appear while the program is sent to the CR800
followed by a confirmation that the transfer was successful. Click OK to
close the confirmation.
4. After sending a program to the CR800, a good practice is to monitor the
measurements to ensure they are reasonable. Select the Monitor Data tab. As
