Section 8.  Operation


where
percent-of-reading = 2500 mV • ±0.06%
= ±1.5 mV
and
offset = (1.5 • 667 µV) + 1 µV
= 1.00 mV
Therefore,
accuracy = ±1.5 mV + 1.00 mV
= ±2.5 mV

Electronic Noise
Electronic "noise" can cause significant error in a voltage measurement,
especially when measuring voltages less than 200 mV.    So long as input
limitations are observed, the PGIA ignores voltages, including noise, that are
common to each side of a differential-input pair.    This is the common-mode
voltage.    Ignoring (rejecting or canceling) the common-mode voltage is an
essential feature of the differential input configuration that improves voltage
measurements.
Figure PGIA with Input Signal Decomposition
 (p. 348), illustrates the common-
mode component (V
cm
) and the differential-mode component (V
dm
) of a voltage
signal.  V
cm
 is the average of the voltages on the V+ and V– inputs.  So, V
cm
 =
(V+ + V–)/2 or the voltage remaining on the inputs when V
dm
 = 0.    The total
voltage on the V+ and V– inputs is given as V+ = V
cm
 + V
dm
/2, and V
L
 = V
cm
 –
V
dm
/2, respectively.

8.1.3  Pulse Measurements — Details
Related Topics:
 •  Pulse Measurements — Specifications
 •  Pulse Measurements — Overview
(p. 70)
 •  Pulse Measurements — Details (p. 369)

Read More    Review the PULSE COUNTERS (p. 369) and Pulse on C
Terminals sections in Specifications (p. 91). Review pulse measurement
programming in CRBasic Editor Help for the PulseCount() and TimerIO()
instructions.
