Appendix A. Info Tables and Settings
539
Comms
MemFree(3)
Numeric Y
• Status table field: ≈27
An integer specifying four two-digit fields, read from left to right as (1) number of output
packets waiting to be sent, (2) number of input packets waiting to be serviced, (3) number
of big packets available for TCP/IP comms, and (4) number of little packets available for
TCP/IP comms. Value at start up with no TCP/IP comms is 1530 (no output packets, no
input packets, 15 big packets, and 30 little packets). As TCP/IP comms commence, the
output and input queues increase from 0, big packets decrease from 15, and little packets
decrease from 30. These values are reported in IPTraceComport
(p. 503) setting every 30
seconds as sendq, recvdq, bigfreeq, and lilfreeq. Updated when status is queried. The
following expressions decode the values:
lilfreeq = CommsMemFree(3) % 100
bigfreeq = (CommsMemFree(3) / 100) % 100
rcvdq = (CommsMemFree(3) / 10000) % 100
sendq = (CommsmemFree(3) / 1000000) % 100
A
CompileResults
String Y
• Station Status field: Results for Last Program Compiled
• Status table field: ≈18
Contains error messages generated at compilation or during runtime. Updated after compile.
Also appended to at run time for run time errors such as variable out of bounds.
CPUDriveFree
Numeric Y
• Keyboard: Settings (Datalogger)
Bytes remaining on the CPU: drive.
CSIO1net
Enable
Numeric
• Settings Editor: CS I/O IP | Enabled #2
CSIO2net
Enable
Numeric
• Settings Editor: CS I/O IP | Enabled (#1)
CSIOInfo
String
• Settings Editor: CS I/O | {info box}
2
Order and definitions of auto self-calibration array elements:
(1) 5000 mV range 250 ms integration
(2) 2500 mV range 250 ms integration
(3) 250 mV range 250 ms integration
(4) 25 mV range 250 ms integration
(5) 7.5 mV range 250 ms integration
(6) 2.5 mV range 250 ms integration
(7) 5000 mV range 60 Hz integration
(8) 2500 mV range 60 Hz integration
(9) 250 mV range 60 Hz integration
(10) 25 mV range 60 Hz integration
(11) 7.5 mV range 60 Hz integration
(12) 2.5 mV range 60 Hz integration
(13) 5000 mV range 50 Hz integration
(14) 2500 mV range 50 Hz integration
(15) 250 mV range 50 Hz integration
(16) 25 mV range 50 Hz integration
(17) 7.5 mV range 50 Hz integration
(18) 2.5 mV range 50 Hz integration
