4.2 Initial Checks
77
4
Troubleshooting
Images on the copy
are skewed.
Is the document loaded correctly? Load the document correctly.
See “1.2 Loading Documents” (P. 270) in
“Part 2 Copier”.
Is paper loaded correctly in the tray?
Are the paper guides in tray 5 (Bypass
Tray) set so that they are contacting
the paper?
Load paper correctly.
“2.1 Loading Paper” (P. 28)
Is the DADF document guide at the
correct position?
Load the document correctly, and align
the document guide with the edge of the
document.
See “1.2.2 Loading Copies on the DADF”
(P. 271) in “Part 2 Copier”.
Is the paper tray set properly? Firmly push in the tray as far as possible
to set it properly.
“2.1 Loading Paper” (P. 28)
Part of the image is
missing on the
copy.
Is the paper damp? If the paper is damp, either some parts
of the copy are not shown or the copy is
smudged and unclear. Replace with
paper from a new ream.
“2.1 Loading Paper” (P. 28)
Is the loaded paper folded or wrin-
kled?
Remove the defective paper and replace
with paper from a new ream.
“2.1 Loading Paper” (P. 28)
Is the document pasted together or
folded in?
A probable cause is that the pasted or
folded in section is curling back, and has
risen up from the surface of the docu-
ment glass. Place a stack of white
sheets on the document to hold the doc-
ument down flat against the document
glass.
A stripe pattern
appears in copies.
Is too large a document enlargement
ratio set?
Stripes sometimes appear in copies at
some enlargement ratios. Adjust the
copy enlargement ratio.
See “3.4 Making Enlarged/Reduced Copies -
Reduce/Enlarge” (P. 306) in “Part 2
Copier”.
Symptoms Check Remedy
To Next Page
