The machine has ventilation holes. Ensure that the machine is installed with a minimum
clearance of 100mm from the rear vent to the wall. A poorly ventilated machine can cause
excessive internal heat and fire. The accompanying diagrams show the minimum clear-
ances required for normal operation, consumables replacement and maintenance to ensure
your machine operates at peak performance. Your Xerox representative will provide neces-
sary support for the proper installation of the machine.
1067
400
425
780
100
1705
96750 50
Without DADF
(unit : mm)
1461
400
425
780
100
1705
136150 50
(unit : mm)
With DADF
2117
305
1705
50
400
425
780
100
50
2217
(unit : mm)
With staple finisher (option) and side tray (option)
