3.2 Replacing Consumables
56
3
Daily Care
Procedure
1
Make sure that the machine has
stopped before opening the front cover.
2
Lift up the stopper on the left front of the
machine while pressing the bottom of
the stopper upwards.
3
Pull down the handle.
This unlocks the drum cartridge lock so that the four
drum cartridges can be accessed.
4
Gently draw out the drum cartridge (A1,
A2, A3, A4) indicated on the display by
gripping its handle.
The following example shows how to replace drum A4.
When pulling out a drum cartridge, take care not to drop
it on the floor.
Drum cartridge
To Next Page
