Chapter 4 Disassembly / Assembly and Adjustment
4.2 Removal / Replacement
4-106
[Replacement]
NOTE
When installing the HVPS, confirm that the ends of the three conductive springs provided on the
frame are in contact with the terminals on the board, and that the two SENSORs on the HVPS is cor-
rectly aligned with the SHUTTER SENSOR REG.
