Chapter 6 General
6.6 IOT Diag
6-47
Digital Output Test Example
This section contains an example of 071-002: Main Motor (Half), and an example of 071-006: Regi
Clutch.
1 Enter the CE mode. (See "6.4.2 How to Enter the CE Mode".)
2 Confirm that [Printer Diag] is selected, and then press the [OK] button.
3 Use the [T] button to select [IOT Diag], and then press the [OK] button.
4 Use the [T] button to select [Digital Output], and then press the [OK] button.
5 To set LVPS 24V to On, use the [S] or [T] button to select [041-001].
6 Press the [OK] button.
7 To continue checking the operation of Main Motor (Half), do not press the press [C(Clear)] but-
ton. Use the [S] or [T] button to select [071-002].
8 Press the [OK] button. Check the operation noise.
Printer Diag
IOT Diag
IOT Diag
Digital Input
IOT Diag
Digital Output
Digital Output
010-001 READY
Digital Output
041-001 READY
Digital Output
041-001 EXEC
Digital Output
071-002 READY
Digital Output
071-002 EXEC
To Next Page
