Chapter 6 General
6.6 IOT Diag
6-48
NOTE
Press the [C(Clear)] button to stop the test.
9 To continue checking the operation of Regi Clutch, do not press the [C(Clear)] button. Use the
[S] or [T] button to select [071-006].
10 Press the [OK] button. Check the operation noise.
11 To stop the operation of Regi Clutch, press the [C(Clear)] button.
12 To stop the operation of Main Motor (Half), use the [S] or [T] button to select [071-002], and
then press the [C(Clear)] button.
13 To turn off LVPS 24V, use the [S] or [T] button to select [041-001], and then press the
[C(Clear)] button.
14 Press the [C(Clear)] button to return to the [Printer Diag] screen.
15 Exits the CE mode. (See "6.4.4 How to Exit the CE Mode".)
Digital Output
071-006 READY
Digital Output
071-006 EXEC
Digital Output
071-006 READY
Digital Output
071-002 READY
Digital Output
041-001 READY
Printer Diag
IOT Diag
