Chapter 6 General
6.11 Board Diag (Board Test)
6-75
Dial Pulse Send
DP10 Individually
10 digits
(each digit 0-9)
Sends the multi-digit Dial Pulse (10pps) sig-
nal.
DP20 Individually
10 digits
(each digit 0-9)
Sends the multi-digit Dial Pulse (20pps) sig-
nal.
Ring Back Tone
－
Sends the ring back tone.
Data Send
V.34 33600bps
－
Sends the data of specified speed and pat-
tern. (no pattern for V. 34)
V.34 31200bps
V.34 28800bps
V.34 26400bps
V.34 24000bps
V.34 21600bps
V.34 19200bps
V.34 16800bps
V.34 14400bps
V.34 12000bps
V.34 9600bps
V.34 7200bps
V.34 4800bps
V.34 2400bps
V.29 9600bps
5 patterns
Sends the data of specified speed and pat-
tern.
V.29 7200bps
V.29 4800bps
V.27ter 4800bps
5 patterns
Sends the data of specified speed and pat-
tern.
V.27ter 2400bps
V.21 300bps 5 patterns
Sends the data of specified speed and pat-
tern.
V.17 14400bps
5 patterns
Sends the data of specified speed and pat-
tern.
V.17 12000bps
V.17 9600bps
V.17 7200bps
Line Voltage - Checks the status of the Line Voltage.
Line Current - Checks the status of the Line Current.
Table 6-49 Relay/Signal Test
