5.4 Advanced Settings for Each Channel
100
3. Set the setting method.
In the case of the 8948 Voltage/Temp Unit or 8949 Universal Unit:
In the case of the 8996 Digital/Pulse Unit (totalization measurement):
In the case of the 8996 Digital/Pulse Unit (rotation rate measurement):
Selectable Items Explanations
Set by Ratio Set the ratio and offset.
Set by 2 Points Set the values of any 2 points.
Selectable Items Explanations
Setting Method 1 Set scaling by the physical quantity per pulse.
Setting Method 2 Set scaling by the number of pulses per fundamental unit.
Selectable Items Explanations
Set by Ratio Set the ratio and offset.
Set by 2 Points Set the values of any 2 points.
Select
Select
Select
