7.3 Changing Display Settings
146
You can use the scrollbar to confirm what the position of the waveform portion
displayed on the screen is within the whole recorded waveform. The scrollbar
has two knobs, and color is used to emphasize the active knob. The positions
of the cursors A and B are also indicated.
When One Screen (Split Screen OFF)
Confirming Position of Displayed Waveform Portion with Scrollbar
Screen display range
Clicking knob 2 changes the screen display range.
Whole waveform
Whole waveform
Screen display range
Knob 1
Knob 2
Knob 1
Knob 2
Scrollbar
