7.6 Searching for the Maximum Value, Minimum Value, and Variation
157
7
Chapter 7 Analyzing Measurement Data
Local Maximum
Position/
Local Minimum
Position
Search for the maximum value or minimum value near the reference value.
• The initial reference value is the measurement start point.
• The previous search position becomes the reference point once a search has
been performed.
Alarm Position Search for the position that the alarm status became ON, or the position that it
became OFF. (When an 8997 Alarm Unit is connected, and alarm measurement
is set to ON)
Level Search for a portion where any channel measurement value crosses the speci-
fied value.
Window Search for the portion where any channel value enters (or exits) the specified
range.
Local max. value
Local max. value
Reference value
Reference value
Level
Level
Up
Up Up
Slope
Slope
Down
Down
Down
