Contents
iii
5.7 Setting Environment Conditions ......................................121
5.7.1 Setting External Control Input Terminals ..............................121
5.7.2 CF Card Save Settings .........................................................123
5.7.3 Time Value Display ...............................................................125
5.7.4 Start Backup .........................................................................126
5.8 Send Settings ..................................................................127
5.9 Process All ......................................................................128
5.10 Narrowing Down of Display Channels ............................129
Chapter 6 Starting and Stopping Measurement131
6.1 Pre-Operation Inspection ................................................134
6.2 Starting and Ending Measurement .................................135
6.2.1 Computer Based Measurement ............................................135
6.2.2 Standalone Measurement ....................................................137
Chapter 7 Analyzing Measurement Data _____ 139
7.1 Changing the Waveform Display Range .........................140
7.2 Checking Cursor Values .................................................141
7.3 Changing Display Settings ..............................................142
7.3.1 Switching between Waveform Display and List Display .......142
7.3.2 Waveform Display Settings ..................................................143
7.3.3 List Display Settings .............................................................148
7.3.4 Common Settings and Auto Update Settings .......................149
7.4 Calculations ....................................................................150
7.4.1 Calculation Settings ..............................................................150
7.4.2 Numerical Calculation Expressions ......................................152
7.5 Event Mark Function .......................................................153
7.5.1 Adding a Mark (Event Mark) to a Waveform ........................153
7.5.2 Searching for and Editing Event Marks ................................154
7.6 Searching for the Maximum Value, Minimum Value,
and Variation ...................................................................155
7.7 Displaying the Channel List ............................................159
7.8 Confirming Measurement Conditions ..............................160
7.9 Monitor Display ...............................................................161
Chapter 8 Saving and Reading Data ________ 163
8.1 Saving and Reading Measurement Data ........................164
8.1.1 Saving Measurement Data as Text ......................................164
8.1.2 Converting Measurement Data to an Excel File ...................167
4
5
6
7
8
3
To Next Page
