Huawei Quidway S2000 Series User Manual

Command Manual - STP
Quidway S2000 Series Ethernet Switches Chapter 1 RSTP Configuration Commands
1-2
The Port is a non-edged port
Connected to a point-to-point LAN segment
Maximum transmission limit is 3 Packets / hello time
Times: Hello Time 2 sec, Max Age 20 sec
Forward Delay 15 sec, Message Age 0
BPDU sent: 0
TCN: 0, RST: 0, Config BPDU: 0
BPDU received: 0
TCN: 0, RST: 0, Config BPDU: 0
Table 1-1 the display Information
Field Description
Protocol mode Current switch is executing RSTP.
The bridge ID (Pri.MAC): 32768.00e0-fc00-5516
The bridge times: Hello Time 2 sec, Max Age 20
sec, Forward Delay 15 sec
Root bridge ID(Pri.MAC): 32768.00e0-fc00-5516
Root path cost: 0
Bridge bpdu-protection: disabled
The RSTP configuration of the switch, including priority
and MAC address of local bridge, Configured time
parameter (Hello Time, Max Age, Forward Delay), priority
and MAC address of root bridge, the path cost from this
switch to the root.
Port 2 (Ethernet0/2) of bridge is DOWN
Port spanning tree protocol: enabled
Port role: DisabledPort
Port path cost: 200000
Port priority: 128
Designated bridge ID(Pri.MAC):
32768.00e0-fc00-5516
The Port is a non-edged port
Connected to a point-to-point LAN segment
Maximum transmission limit is 3 Packets /
hello time
Times: Hello Time 2 sec, Max Age 20 sec
Forward Delay 15 sec, Message Age
0
BPDU sent: 0
TCN: 0, RST: 0, Config BPDU: 0
BPDU received: 0
TCN: 0, RST: 0, Config BPDU: 0
The RSTP configuration of port 2, including the port’s
status is forwarding, the port RSTP is enabled, this port is
Designated Port, the cost to root of this port , the priority
of this port, the priority and MAC address of Designated
bridge, this port is configured as an edge port, the link of
this port is non-point-to-point, Maximum transmission
limit is 3 BPDUs per hello time, configured RSTP time
parameters(Hello Time, Max Age, Forward Delay,
Message Age), the statistics of BPDU (TCN specifies the
number of topology-change-notify datagram, RST
specifies the number of RSTP datagram, Config BPDU
specifies the number of STP datagram)
1.1.2 reset stp
Syntax
reset stp [ interface interface_list ]
View
User view
Parameter
interface interface_list: Specifies the Ethernet port list, including multiple Ethernet
ports. Expressed as interface _list = { { interface_type interface_num | interface_name }
