Huawei Quidway S6500 Series User Manual

Operation Manual - QoS/ACL
Quidway S6500 Series Ethernet Switches Chapter 1 ACL Configuration
Huawei Technologies Proprietary
1-4
Item Value range Maximum
Numbered User-defined ACL 5000 to 5999 -
The sub items of an ACL 0 to 127 128
1.2 Configure ACL
ACL configuration includes:
z Configure time range
z Define ACL
z Activate ACL
The above three steps had better be taken in sequence. Configure time range first and
then define ACL (using the defined time range in the definition), followed activating ACL
to validate it.
1.2.1 Configure Time-Range
The process of configuring a time-range includes the steps of configuring the
hour-minute range, date ranges and period range. The hour-minute range is expressed
in the units of minute, hour. Date range is expressed in the units of minute, hour, date,
month and year. The periodic time range is expressed in the day of the week.
You can use the following command to set the time range by performing the following
configuration in the system view.
Table 1-3 Set the absolute time range
Operation Command
Set the absolute
time range
time-range time-name { start-time to end-time
days-of-the-week [ from start-time start-date ] [ to end-time
end-date ] | from start-time start-date [ to end-time end-date ]
| to end-time end-date }
Delete the absolute
time range
undo time-range time-name [ start-time to end-time
days-of-the-week [ from start-time start-date ] [ to end-time
end-date ] | from start-time start-date [ to end-time end-date ]
| to end-time end-date ]
start-time and end-time days-of-the-week define period time range together. from
start-time start-date and end-time end-date define absolute time range together.
If a time range only defines the period time range, the time range is only active within
the period time range.
