Huawei Quidway S6500 Series User Manual

Operation Manual - System Management
Quidway S6500 Series Ethernet Switches Chapter 5 SNMP Configuration
Huawei Technologies Proprietary
5-9
5.4 Display and Debug SNMP
After the above configuration, execute display command in any view to display the
running of the SNMP configuration, and to verify the effect of the configuration. Execute
debugging command in user view to debug SNMP configuration.
Table 5-16 Display and debug SNMP
Operation Command
Display the statistics
information about SNMP
packets
display snmp-agent statistics
Display the engine ID of the
active device
display snmp-agent { local-engineid |
remote-engineid }
Display the group name, the
security mode, the states for all
types of views, and the storage
mode of each group of the
switch.
display snmp-agent group [ group-name ]
Display the names of all users
in the group user table
display snmp-agent usm-user [ engineid
engineid ] [ group groupname ] [ username
username ]
Display the current community
name
display snmp-agent community [ read | write ]
Display the current MIB view
display snmp-agent mib-view [ exclude |
include | { viewname mib-view } ]
Display the contact character
string of the system
display snmp-agent sys-info contact
Display the location character
string of the system
display snmp-agent sys-info location
Display the version character
string of the system
display snmp-agent sys-info version
5.5 SNMP Configuration Example
I. Networking requirements
Network Management Station and the Ethernet switch are connected via the Ethernet.
The IP address of Network Management Station is 129.102.149.23 and that of the
VLAN interface on the switch is 129.102.0.1. Perform the following configurations on
the switch: setting the community name and access authority, administrator ID, contact
and switch location, and enabling the switch to sent trap packet.
