Huawei Quidway S6500 Series - Setting Priority-Output Queue Mapping and Queue Scheduling

Operation Manual - QoS/ACL
Quidway S6500 Series Ethernet Switches Chapter 2 QoS Configuration
Huawei Technologies Proprietary
2-9
2.2.3 Setting Priority-Output Queue Mapping and Queue Scheduling
Queue scheduling is often used in solving the problem of resource contention during
network congestion.
Each port supports eight outbound queues. The switch can distribute packets into the
target queues according to several types of priority. The following tables show the
mapping between outbound queues and priority schemes.
Table 2-4 Mapping between 802.1p priority levels and outbound queues
802.1p priority level Queues
0 2
1 0
2 1
3 3
4 4
5 5
6 6
7 7
Table 2-5 Mapping between local priority levels and outbound queues
Local priority level Queue
0 0
1 1
2 2
3 3
4 4
5 5
6 6
7 7
