Operation Manual - System Management
Quidway S6500 Series Ethernet Switches Chapter 3 Device management
Huawei Technologies Proprietary
3-12
[Quidway-Ethernet4/0/1]
4) Specify only detect current interface for error packets of runt type.
[Quidway-Ethernet4/0/1] qe monitor errpkt runt
3.8 Display and Debug Device Management
After the above configuration, execute display command in any view to display the
running of the device management configuration, and to verify the effect of the
configuration.
Table 3-15 Display and debug device management
Operation Command
Display the set back board view. (Salience III
series engines do not support this operation.)
display backboard view
Display CPU occupancy. display cpu [slot id ]
Display the module types and running states
of each card.
display device [ detail | [ shelf
shelf-no ] [ frame frame-no ] [ slot
slot-num ] ]
Display the running state of the built-in fans. display fan [ fan-id ]
Display the information about the
environment.
display environment
Display the Used status of switch memory display memory [ slot slot-num ]
Display the state of the power.
display power [ powe-id ]
3.9 Device Management Configuration Example
I. Networking requirement
The user logs into the switch using Telnet, downloads the application from the FTP
server to the flash memory of the switch, and implements remote upgrade using the
right commands.
The switch serves as FTP client and the remote PC as FTP server. The configuration
on FTP server: Configure a FTP user named as switch, with password hello and with
read & write authority over the Switch root directory on the PC. The IP address of a
VLAN interface on the switch is 1.1.1.1, and that of the PC is 2.2.2.2. The switch and
PC are reachable.
The switch applications switch.app and boot.app are stored on the PC. Using FTP, the
switch can download the switch.app and boot.app from the remote FTP server.
