Huawei Quidway S6500 Series User Manual

Operation Manual - System Management
Quidway S6500 Series Ethernet Switches Chapter 2 MAC Address Table Management
Huawei Technologies Proprietary
2-4
2.2.4 Set the processing method for the specific packets
You can use the following commands to configure whether or not the packets with
destination MAC addresses being bridge MAC address of the switch are passed to
CPU for being processed.
Perform the following configuration in system view.
Table 2-4 Set the processing method for the specific packets
Operation Command
Configure the packets with destination MAC
addresses being bridge MAC address to be passed
to CPU for being processed.
bridgemactocpu enable
Configure the packets with destination MAC
addresses being bridge MAC address not to be
passed to CPU
bridgemactocpu disable
By default, the packets with destination MAC addresses being bridge MAC address are
not to be passed to CPU for being processed.
2.3 Display MAC Address Table
After the above configuration, execute display command in any view to display the
running of the MAC address table configuration, and to verify the effect of the
configuration.
Execute debugging command in user view to debug MAC address table configuration.
Table 2-5 Display and debug MAC address table
Operation Command
Display the information in the
address table
display mac-address [ mac-addr [ vlan vlan-id ]
| [ static | dynamic ] [ interface { interface-name
| interface-type interface-num } ] [ vlan vlan-id ]
[ count ] ]
Display the aging time of
dynamic address table entries
display mac-address aging-time
2.4 MAC Address Table Management Configuration Example
I. Networking requirements
The user logs in the switch via the Console port to configure the address table
management. It is required to set the address aging time to 500s and add a static
address 00e0-fc35-dc71 to Ethernet1/0/2 in vlan1.
