Quidway S6500 Series Ethernet Switches Chapter 3 ACL Configuration
Huawei Technologies Proprietary
3-3
 Note:
Currently you can import only the basic and advanced ACLs with digit IDs.
3.2.3 Configuration Example
I. Networking requirement
Only the Telnet users from 10.110.100.52 and 10.110.100.46 can access the switch.
II. Networking diagram
Internet
Switch
Figure 3-1 ACL configuration for Telnet users
III. Configuration procedure
# Define a basic ACL.
[Quidway] acl number 2000 match-order config
[Quidway-acl-basic-2000] rule 1 permit source 10.110.100.52 0
[Quidway-acl-basic-2000] rule 2 permit source 10.110.100.46 0
[Quidway-acl-baisc-2000] rule 3 deny source any
[Quidway-acl-basic-2000] quit
# Import the ACL.
[Quidway] user-interface vty 0 4
[Quidway-user-interface-vty0-4] acl 2000 inbound
