1.4.4 Specify the ACL rule on TFTP connection
You can use the following commands to specify the ACL rule when the TFTP client is
making a connection with the TFTP server.
Perform the following configuration in system view.
Table 1-18 Specify the ACL rule on TFTP connection
Operation Command
Specify the ACL rule when the TFTP client is
making a connection with the TFTP server.
tftp-server acl acl-num
cancel the specified ACL rule
undo tftp-server acl
1.4.5 TFTP Client Configuration Example
I. Networking requirement
The switch serves as TFTP client and the remote PC as TFTP server. Authorized TFTP
directory is set on the TFTP server. The IP address of a VLAN interface on the switch is
1.1.1.1, and that of the PC is 2.2.2.2. The interface on the switch connecting the PC
belong to the same VLAN.
The switch application switch.app is stored on the PC. Using TFTP, the switch can
download the switch.app from the remote TFTP server and upload the vrpcfg.txt to the
TFTP server under the switch directory for backup purpose.
II. Networking diagram
Switch
PC
Network
SwitchSwitch
PC
Network
Figure 1-5 Networking for TFTP configuration
III. Configuration procedure
1) Start TFTP server on the PC and set authorized TFTP directory.
2) Configure the switch
# Log into the switch (locally through the Console port or remotely using Telnet).
<Quidway>
