Operation Manual - System Management
Quidway S6500 Series Ethernet Switches Chapter 6 RMON Configuration
Huawei Technologies Proprietary
6-5
II. Networking diagram
Console Port
Network Port
Switch
Internet
Figure 6-1 RMON configuration networking
III. Configuration procedure
# Configure RMON.
[Quidway-Ethernet3/0/1] rmon statistics 3 owner abc
# View the configurations in user view.
<Quidway> display rmon statistics Ethernet 3/0/1
Statistics entry 3 owned by abc is VALID.
Interface : Ethernet3/0/1<ifIndex.201326722>
etherStatsOctets : 3776 , etherStatsPkts : 30
etherStatsBroadcastPkts : 0 , etherStatsMulticastPkts : 30
etherStatsUndersizePkts : 0 , etherStatsOversizePkts : 0
etherStatsFragments : 0 , etherStatsJabbers : 0
etherStatsCRCAlignErrors : 0 , etherStatsCollisions : 0
etherStatsDropEvents (insufficient resources): 0
Packets received according to length (etherStatsPktsXXXtoYYYOctets):
64 : 5 , 65-127 : 10 , 128-255 : 15
256-511: 0 , 512-1023: 0 , 1024-max : 0
