v 2.0 — March 2023 Altanium Delta5
204 Data Collection Stop Conditions
Yes Yes Yes Yes If pair of digital inputs (start and end):
• End digital input does not go
high before the cycle time limit
has expired
• Heats are turned off or not At
Temperature
• UltraSync-E is disengaged or
disabled
• Mold Servo Controller is
disengaged or disabled
System changes to timed data
collection
If one digital input to start and timer
to end data acquisition:
• Start digital input is not high
again before the cycle time limit
has expired
• Heats are turned off or not At
Temperature
• UltraSync-E is disengaged or
disabled
• Mold Servo Controller is
disengaged or disabled
System changes to timed data
collection
If one digital input to start and end
data acquisition:
• Start digital input does not go
high again before the cycle time
limit has expired
• Heats are turned off or not At
Temperature
• UltraSync-E is disengaged or
disabled
• Mold Servo Controller is
disengaged or disabled
System changes to timed data
collection
Table 12-5 Cycle Mode - Conditions to Stop (UltraSync-E or Altanium Servo Control Installed) (Continued)
