Data Collection Stop Conditions 205
User Guide v 2.0 — March 2023 Data Recording
No Yes No No If pair of digital inputs (start and end):
• End digital input does not go
high before the cycle time limit
has expired
• UltraSync-E is disengaged or
disabled
System does not change to timed
data collection
If one digital input to start and timer
to stop data acquisition:
• Start digital input is not high
again before the cycle time limit
has expired
• UltraSync-E is disengaged or
disabled
System does not change to timed
data collection
If one digital input to start and end
data acquisition:
• Start digital input does not go
high again before the cycle time
limit has expired
• UltraSync-E is disengaged or
disabled
System does not change to timed
data collection
Table 12-5 Cycle Mode - Conditions to Stop (UltraSync-E or Altanium Servo Control Installed) (Continued)
Heats Running
Condition
Enabled
UltraSync-E
Engaged
Condition
Enabled
Mold Servo
Controller
Engaged
Condition
Enabled
Cycle Mode
Conditions
Selection
Shown on
Screen
Conditions to Stop
To Next Page
