v 2.0 — March 2023 Altanium Delta5
252 Heats Digital Outputs
Table 14-8 describes the heats output signals on the Heat Page 1 tab.
Table 14-8 Heats Output Signals (Heats Page 1)
Signal Description
Alarm Activated when an Alarm or Abort condition occurs. This state stays until
the alarm condition is CLEARED or RESET.
Abort (PCM) Activated when an Abort condition occurs, and the Priority Control
Mode (PCM) setting in the Quick Set screen is set to System. This state
stays until the alarm condition is CLEARED or RESET.
At Temperature Activated only when all zones are above their Under Temperature alarm
limit. This state stays until a zone drops below its Under Temperature
alarm limit or the controller is put into Stop mode.
Remote Standby Activated when the controller has received the Remote Standby input
signal.
At Boost Temperature Activated only when all zones with a Remote Boost setpoint are above
their Under Temperature alarm limit while in BOOST mode. This state
stays until a zone drops below its Under Temperature alarm limit or the
controller is put into Stop mode.
NOTE: If one or more zones go above the Over Temperature alarm limit
the state will stay.
At Standby
Temperature
Activated only when all zones with a Remote Standby setpoint are
above their Under Temperature alarm limit while in Standby mode. This
state stays until a zone drops below its under temperature alarm limit or
the controller is put into Stop mode.
NOTE: If one or more zones go above the Over Temperature alarm limit
the state will stay.
Max Temperature Error Activated when one or more zones exceed the Over Maximum
Temperature limit.
Communications Error Activated if the controller stops communicating with a control card. This
state stays until communications are in operation again.
Mold Cooling Enable Activated when all temperatures are greater than the Mold Cooling
Enabled Limit.
NOTE: All temperatures must be equal to or lower than the Mold
Cooling Enabled Limit before the signal is deactivated, after the
system is in STOP mode.
Process Outside Limit Activated if any critical process parameter violates its threshold setting.
NOTE: The threshold setting is in the Process Monitoring - Limits
screen.
Run Light Activated whenever the START button is pressed. This state stays until
the system is placed in STOP mode.
