FLIGHT CONTROLS / FLAP CONTROLS 9-67
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
CHAPTER 9
VERIFICATION METHOD:
Record results and check deflection limits relative to the 0° position.
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Wings" on page 3-11
"Exterior/Interior Wing Control Surfaces" on page 17-5
"Remove Flap Actuator" on page 9-71
"Install Flap Gas Strut" on page 9-77
"Install Flap Actuator" on page 9-74
"Flap Hinge Repair Procedure" on page 17-22
"Main Landing Gear (MLG) Removal" on page 14-37
"Main Landing Gear (MLG) Installation" on page 14-38
"Flap Surface Installation" on page 17-20
"Rigging Flap Controls" on page 9-67
9.9.3.2 Rigging Flap Controls
Use the following procedure for flap rigging.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
A&P
Task Specific Training Required
No
Special Tools Required
Aircraft Cable Tensiometer
Parts Required
As needed based upon inspections and condition of parts. Contact ICON Aircraft for assistance
as needed. A list of part numbers in the flap cable system is below.
Left Flap ____° Up (See Step 2) ____° Mid (15±3°) ____° Down (30±3°)
Right Flap ____° Up (See Step 2) ____° Mid (15±3°) ____° Down (30±3°)
