CHAPTER 7
Power Subsystem
IN THIS CHAPTER
MX2020 Power Subsystem Description | 91
MX2020 Power Midplane Description | 96
MX2000 Three-Phase Delta AC Power Distribution Module Description | 96
MX2000 Three-Phase Wye AC Power Distribution Module Description | 98
MX2000 Seven-Feed Single-Phase AC Power Distribution Module Description | 101
MX2000 Nine-Feed Single-Phase AC Power Distribution Module Description | 102
MX2000 Three-Phase Delta and Wye AC Power Distribution Module LEDs | 103
MX2000 AC Power Supply Module Description | 103
MX2020 AC Power Supply Module LEDs | 106
MX2020 DC Power Distribution Module (-48 V) Description | 107
MX2000 DC Power Distribution Module (240 V China) Description | 109
MX2020 DC Power Distribution Module (-48 V) LEDs | 110
MX2000 DC Power Distribution Module (240 V China) LEDs | 111
MX2020DC Power Supply Module (-48 V) Description | 112
MX2000 DC Power Supply Module (240 V China) Description | 115
MX2020 DC and Power Supply Module LEDs | 117
MX2020 Power Subsystem Description
The MX2000 routers are available in -48 V and 240 V China DC power configurations, three-phase (delta
and wye) AC power configurations, and a single-phase power configuration. You can add additional power
to the rack as needed. The MX2020 router is configurable with up to four AC or DC power distribution
modules (PDMs) (two per subsystem), and up to eighteen AC or DC power supply modules (PSMs). The
PSMs connect to the top and bottom power backplanes that distribute the output voltages produced by
the PSMs to the router components.
Table 24 on page 92 describes the MX2020 DC power components and Table 25 on page 93 describes
the MX2020 AC power components.
