Table 47: RJ-45 to DB-9 Serial Port Adapter Pinout Information (continued)
SignalDB-9 PinSignalRJ-45 Pin
DSR6DTR2
RXD2TXD3
GND5GND4
TXD3RXD6
DTR4DSR7
RTS7CTS8
Mini-USB Port Pinout Specifications
If your management host (laptop or PC) does not have a DB-9 male connector pin or an RJ-45 connector
pin but has a USB port, you can connect your management host to the Mini-USB Type-B console port by
using a cable that has a standard Type-A USB connector on one end and a Mini-USB Type-B (5-pin)
connector on the other end.
The Mini-USB Type-B console port uses a Mini-USB Type-B connector to connect to a console management
device. The default baud rate for the console port is 9600 baud.
Table 48 on page 159 provides the pinout information of the Mini-USB Type-B console port.
Table 48: Mini-USB Type-B Console Port Pinout Information
DescriptionSignalPin
+5 VDCVCC1
Data -D-2
Data +D+3
Could be not connected (N/C), connected to ground (GND), or used as an attached
device presence indicator
N/CX
GroundGND4
159
