WARNING: Do not look directly into a fiber-optic transceiver or into the ends
of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable connected
to a transceiver emit laser light that can damage your eyes.
8. Verify that the status LEDs on the component faceplate indicate that the SFP or XFP is functioning
correctly. For more information about the component LEDs, see the MX Series Interface Module Reference.
SEE ALSO
Removing an SFP or XFP Transceiver from an MX2020 MPC or MIC | 565
RELATED DOCUMENTATION
Preventing Electrostatic Discharge Damage to an MX2020 Router
Replacing an MX2020 MIC | 553
Replacing an MX2020 MPC and Adapter Card (ADC) | 536
Installing an SFP or XFP into an MX2000 MPC or MIC
To install an SFP or XFP:
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
one of the ESD points on the chassis.
2. Take each transceiver to be installed out of its electrostatic bag, and identify the slot on the component
where it will be installed.
3. Verify that each transceiver is covered by a rubber safety cap. If it is not, cover the transceiver with a
safety cap.
4. Carefully align the transceiver with the slots in the component. The connectors should face the
component.
5. Slide the transceiver until the connector is seated in the component slot. If you are unable to fully insert
the transceiver, make sure the connector is facing the right way.
