6. Close the ejector handle of the transceiver.
7. Remove the rubber safety cap from the transceiver and the end of the cable. Insert the cable into the
transceiver.
WARNING: Do not look directly into a fiber-optic transceiver or into the ends
of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable connected
to a transceiver emit laser light that can damage your eyes.
8. Verify that the status LEDs on the component faceplate indicate that the SFP or XFP is functioning
correctly. For more information about the component LEDs, see the MX Series Interface Module Reference.
RELATED DOCUMENTATION
Removing an SFP or XFP from an MX2010 MPC or MIC
Removing an SFP or XFP Transceiver from an MX2020 MPC or MIC | 565
Prevention of Electrostatic Discharge Damage | 770
Installing an MX2020 Dual-Wide MIC
To install a dual-wide MIC:
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
one of the ESD points on the chassis.
2. Remove the septum, if necessary (see Figure 244 on page 559):
a. Place the MPC on a flat surface. If necessary, remove the MPC from the ADC as described in
“Removing an MX2020 MPC from the Adapter Card” on page 539.
b. Remove the four screws labeled S on the bottom of the MPC.
c. Remove the two screws labeled S on the top of the MPC.
d. Slide the septum toward you and out of the MPC.
569
