Table 73: DC PSM (240 V China) Electrical Specifications Per Input Configurations (continued)
SpecificationItem
2500 WMaximum DC output @
52 VDC (upper and lower
cage)
30 WDC standby output @ 5
VDC
91%Efficiency
NOTE: This value is
within load range
17-67% and nominal
input voltage at 240
VDC.
DC Power Supply Input Fuses
The DC PSM has a power supply input fuse in the negative terminals of both INP0 and INP1.
Table 72 on page 206 lists the electrical specification for this fuse.
Table 74: Electrical Specifications for the DC Power Supply (240 V China) Input Fuse
ValueElectrical Characteristic
Fuse Walter MHP-20Fuse
500 VdcVoltage Rating
20 AAmpere Range
20 kAInterrupting Rating
UL Recognized (File: E71611)Approvals
Body: Glass melamine
Caps: Silver-plated brass
Construction
RoHS Compliant, Lead (Pb) FreeEnvironmental
208
