Figure
106:
Securing
the
Router
Transport
Platform
g000040
Installing
the
MX2020
Router
Using
a
Router
Transport
Kit
Because
of
the
router's
size
and
weight—up
to
1,515
lb
(687.19
kg)
depending
on
the
configuration—you
must
use
either
a
pallet
jack
or
router
transport
kit
to
install
the
router.
NOTE:
You
can
purchase
a
router
transport
kit
from
Juniper
Networks.
NOTE:
Four
persons
are
needed
to
install
the
router
into
a
rack.
270
289
291
