Figure 221: Installing the Air Baffle
g007466
To direct exhaust air away from the router, the louvers on the air baffle must be set to a 10-degree fixed
upward tilt with respect to the horizontal.
RELATED DOCUMENTATION
Maintaining the MX2020 Air Baffle | 467
Removing the MX2020 Air Baffle | 463
