Figure 19: Upper and Lower Extended Cable Management
g000413
LC
10
11
12 13 14 15 16 17 18 19
RELATED DOCUMENTATION
Installing the MX2020 Upper Cable Manager | 621
Installing the MX2020 Lower Cable Manager | 620
Installing the MX2020 DC Cable Manager | 615
Replacing the MX2020 Cable Managers | 616
MX2020 Rack-Mounting Hardware
The rack-mounting hardware for the MX2020 router includes:
•
The large adjustable mounting shelf for mounting in four-post racks or cabinets
•
Front-mounting flanges on the front of the chassis for front-mounting in a four-post rack or cabinet
•
Mounting screws
42
