Table 72: Electrical Specifications for the DC Power Supply Input Fuse (continued)
ValueElectrical Characteristic
Body: Glass melamine
Caps: Silver-plated brass
Construction
RoHS Compliant, Lead (Pb) FreeEnvironmental
RELATED DOCUMENTATION
Calculating DC Power Requirements for MX2020 Routers
MX2020 DC Power Distribution Module (-48 V) Description | 107
MX2020DC Power Supply Module (-48 V) Description | 112
MX2020 DC Power Electrical Safety Guidelines
MX2000 Router DC (240 V China) Power Subsystem Electrical Specifications
Table 71 on page 205 lists the DC power subsystem electrical specifications.
Table 73: DC PSM (240 V China) Electrical Specifications Per Input Configurations
SpecificationItem
16 A (for 2500 W output)Maximum input current
rating input voltage @
190 - 290 VDC
2500 W @ 190 V/16 AMaximum output power
N+1 PSM
N+N feed redundancy
Redundancy
190 VDC to 290 VDCDC input voltage
14 A (for 2500 W output)DC nominal input current
@ 240 VDC IN
207
