12. Remove the winch mount and winch strap plate, and set them aside.
13. Insert sixteen mounting screws (eight on each side) into the mounting holes to secure the router to the
rack.
14. Visually inspect the alignment of the router. To verify that the router is installed properly in the rack,
see that all the mounting screws on one side of the rack are aligned with the mounting screws on the
opposite side and the router is level.
15. Reassemble the router transport kit, and set aside.
RELATED DOCUMENTATION
Overview of Preparing the Site for the MX2020 Router | 121
Tools Required to Install the MX2020 Router Using a Router Transport Kit | 224
Installing the Router Transport Kit on the MX2020 Router | 265
MX2020 Moving Requirements and Guidelines Using a Router Transport Kit | 142
Removing Components from the MX2020 Router Chassis Before Installing it in a Rack | 245
Reinstalling Components in the MX2020 Router After Installing in a Rack | 277
Reinstalling Components in the MX2020 Router After Installing in a Rack
After the router is installed in the rack, remove the shipping covers, and reinstall the removed components
before booting and configuring the router. You reinstall components first in the rear of the chassis, and
then in the front:
1.
Reinstalling the Power Distribution Modules After Installing the MX2020 Router in a Rack | 278
2.
Reinstalling the Power Supply Modules After Installing the MX2020 Router | 281
3.
Reinstalling the Fan Trays After Installing the MX2020 In a Rack | 283
4.
Reinstalling the SFBs After Installing the MX2020 Router in a Rack | 285
5.
Reinstalling the Adapter Card After Installing the MX2020 Router in a Rack | 286
6.
Reinstalling MPCs After Installing the MX2020 Router in a Rack | 287
7.
Reinstalling the CB-REs After Installing the MX2020 Router in a Rack | 288
277
