3. Place the DC cable manager into an electrostatic bag and set it aside.
Figure 267: Removing the Standard DC Cable Manager
RELATED DOCUMENTATION
Installing the MX2020 DC Cable Manager | 615
Installing the MX2020 DC Cable Manager
NOTE: To accommodate additional clearance, you may order an extended DC cable manager
from Juniper Networks.
To install the DC cable manager (see Figure 268 on page 616):
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
one of the ESD points on the chassis.
2. Position the DC cable manager over the two slots located on both sides of the DC PDM.
615
