Table 31: DC Power Distribution Module (240 V China) LEDs

DescriptionStateColor

Positive and negative input feeds are connected. PDM is functioning normally.OnGreen

Positive input feed is not connected or present.Off–

Negative input feed is not connected or present.

RELATED DOCUMENTATION

MX2020 Component LEDs on the Craft Interface

MX2020 Power Subsystem Description | 91

MX2000 DC Power Distribution Module (240 V China) Description | 109

MX2000 Router DC (240 V China) Power Subsystem Electrical Specifications | 207

MX2020DC Power Supply Module (-48 V) Description

The MX2020 supports a two zone DC power system. Each zone (upper and lower) is provided power by

one half of the power subsystem. In the DC power configuration, the router contains up to eighteen DC

PSMs located at the rear of the chassis in slots PSM0 through PSM8 (bottom), and slots PSM9 through

PSM17 (top) (left to right). The DC PSMs in slots PSM0 through PSM8 provide power to the lower half

of the router components, MPCs in slot 0 through 9, CB-REs in slot 0 and 1, SFBs in slot 0 through 7, and

Fan Trays 0, 1, and 2. The DC PSMs in slots PSM9 through PSM17 provide power to the upper half of the

router components, MPCs in slot 10 through 19, CB_REs in slot 0, and 1, SFBs in slot 0 through 7, and

Fan Trays 0, 2, and 3.

NOTE: The MX2020 systems configured for DC input power must use only DC PDMs and DC

PSMs. AC and DC PSMs or PDMs must not be mixed within a single system.

Up to nine PSMs may be connected in parallel to increase available system power across MPCs as needed

and provide redundancy. Figure 50 on page 113) shows the DC PSM.
