Rack-Mounting Requirements
•
You can install the router in a four-post rack or cabinet.
NOTE: The shipping and installation site must be an ESD approved area.
•
The rack rails must be spaced wide enough to accommodate the router chassis's external dimensions:
78.75 in. (200 cm) high, 36.20 in. (91.95 cm) deep, and 19 in. (48.3 cm) wide (see Figure 64 on page 148).
NOTE: A typical four-post rack measures 84 in. (213.4 cm) high, 24 in. (61 cm) to
30 in. (76.2 cm) deep, and 19 in. (48.3 cm) wide.
NOTE: The dimensions also include the standard cable management system and standard
EMI covers.
•
The rack must be able to accommodate the additional depth of the extended cable management system,
37.46 in. (95.1 cm) deep (see Figure 64 on page 148).
•
The rack must be strong enough to support the weight of the fully configured router, up to 1,500 lb
(681.8 kg). See Table 40 on page 146 for MX2020 shipping weight specifications.
Table 40: MX2020 Shipping Weight Specifications
Shipping WeightItem
180 lb (81.8 kg)Shipping crate and pallet
300 lb (136.4 kg)Unpopulated MX2020
480 lb (218.2 kg)Unpopulated MX2020 with shipping crate and pallet
1,680 lb (763.6 kg)Fully populated MX2020 with shipping crate and pallet
NOTE: For a complete list of individual line card and component weights and measurements,
see the MX2020 3D Universal Edge Router Hardware Guide at
https://www.juniper.net/documentation/.
146
