Table 57: MX2020 FRU AC Power Requirements (continued)
Maximum Power RequirementModel NumberComponent
•
When installed into MPC8E:
1.250 A @ 48 V (60 W)
•
When installed into MPC9E:
1.771 A @ 48 V (85 W)
MIC-MRATEMIC MRATE
36 W at 55° C
35 W at 40° C
34 W at 25° C
MIC-3D-8DS3-E3
MIC-3D-8CHDS3-E3-B
DS3/E3 MIC
33.96 WMIC-3D-4COC3-1COC12-CEChannelized OC3/STM1
(Multi-Rate) Circuit Emulation
MIC with SFP
RELATED DOCUMENTATION
MX2020 Power Subsystem Description | 91
Connecting AC Power to an MX2020 Router with Three-Phase Delta AC Power Distribution Modules
Connecting AC Power to an MX2000 Router with Three-Phase Wye AC Power Distribution Modules
Connecting Power to an MX2000 Single-Phase AC Power Distribution Module | 293
MX2020 AC Power Subsystem Electrical Specifications
MX2000 AC Power Cord Specifications | 176
MX2020 AC Power Electrical Safety Guidelines
MX2000 AC Power Cord Specifications
Most sites distribute power through a main conduit that leads to frame-mounted power distribution panels,
one of which can be located next to the rack that houses the router. An AC power cord connects each
power distribution module (PDM) to the power distribution panel. Detachable AC power cords are supplied
with the router. For single–phase PDMs, the coupler type is C21. For three-phase power, the power cord
wires are inserted into the AC input terminal with the help of a screwdriver. The plug end of the power
cord fits into the power source receptacle for your geographical location.
For more information about AC PDM input power mapping, see “Mapping Input Power from AC Power
Distribution Modules to AC Power Supply Modules on MX2000 Routers” on page 190.
