CAUTION: Slide the MIC straight into the slot to avoid damaging the
components on the MIC.
5. Push the MPC6E ejector lever in the direction opposite to the arrow, to return the ejector lever to its
original position. The ejector lever no longer blocks access to the adjacent MPC.
RELATED DOCUMENTATION
MPC6E
Replacing an MX2008 MIC
Replacing an MX2010 MIC
Replacing an MX2020 MIC | 553
MIC/MPC Compatibility
RELATED DOCUMENTATION
Preventing Electrostatic Discharge Damage to an MX2020 Router
MX2000 Modular Interface Card (MIC) Description | 65
Maintaining MX2020 MICs | 525
Troubleshooting the MX2020 MICs | 681
Maintaining MX2020 MICs
Purpose
For optimum router performance, verify the condition of the Modular Interface Cards (MICs).
Action
On a regular basis:
•
Check the LEDs on MIC faceplates. The meaning of the LED states differs for various MICs. For more
information, see the MX Series Interface Module Reference. If the MPC that houses the MIC detects a
MIC failure, the MPC generates an alarm message to be sent to the Routing Engine.
•
Issue the CLI show chassis fpc pic-status command. The MIC slots in an MPC are numbered PIC 0/1
and PIC 2/3, top to bottom:
563
