MX2020 Port and Interface Numbering
In the physical part of the interface name, a hyphen (-) separates the media type from the MPC number
(represented as an FPC in the CLI), and a slash (/) separates the logical PIC and port numbers:
type-fpc/pic/port
•
type—Media type, which identifies the network device. For example:
•
ge—Gigabit Ethernet interface
•
so—SONET/SDH interface
•
xe—10-Gigabit Ethernet interface
For a complete list of media types, see Interface Naming Overview.
•
fpc—Slot in which the MPC is installed. On the MX2020 router, the MPCs are represented in the CLI as
FPC 0 through FPC 19.
•
pic—Logical PIC on the MIC. The number of logical PICs varies depending on the type of MIC.
•
port—Port number.
NOTE: The MIC number is not included in the interface name.
The MX2020 supports up to twenty MPCs that install vertically and are numbered from left to right.
The following sample CLI output displays an MPC (MPC Type 2 3D EQ) installed in MPC slot 19.
user@host> show chassis hardware
...
FPC 19 REV 34 750-031090 ZT9647 MPC Type 2 3D EQ
CPU REV 06 711-030884 ZS1148 MPC PMB 2G
MIC 0 REV 07 750-028387 JZ8700 3D 4x 10GE XFP
PIC 0 BUILTIN BUILTIN 2x 10GE XFP
Xcvr 0 REV 01 740-014289 C701XU069 XFP-10G-SR
Xcvr 1 REV 02 740-014289 C810XU09M XFP-10G-SR
PIC 1 BUILTIN BUILTIN 2x 10GE XFP
Xcvr 0 REV 03 740-011571 C939BK04B XFP-10G-SR
Xcvr 1 NON-JNPR CA49BK02B XFP-10G-SR
MIC 1 REV 26 750-028392 ZT3624 3D 20x 1GE(LAN) SFP
PIC 2 BUILTIN BUILTIN 10x 1GE(LAN) SFP
Xcvr 0 REV 01 740-011613 PAM3CCK SFP-SX
