Xcvr 1 REV 01 740-011782 PAR1L27 SFP-SX
Xcvr 2 REV 01 740-011613 PDQ4XH4 SFP-SX
Xcvr 4 REV 02 740-011613 AM1113SK1K7 SFP-SX
Xcvr 5 REV 01 740-011782 P9P0XXH SFP-SX
Xcvr 6 REV 02 740-011613 PJT1CSS SFP-SX
Xcvr 7 REV 01 740-011782 PAR1YHC SFP-SX
Xcvr 8 REV 02 740-011613 AM0925SBG0L SFP-SX
PIC 3 BUILTIN BUILTIN 10x 1GE(LAN) SFP
Xcvr 0 REV 01 740-011613 P9F13CH SFP-SX
Xcvr 1 REV 01 740-011782 PAR1L2E SFP-SX
Xcvr 2 REV 01 740-011782 P9M0TLC SFP-SX
Xcvr 3 REV 01 740-011613 PAM6KBK SFP-SX
Xcvr 4 REV 01 740-011613 PAM3WLY SFP-SX
Xcvr 5 REV 02 740-011613 PFQ4NUW SFP-SX
Xcvr 6 REV 02 740-011613 AM1003SFUZH SFP-SX
Xcvr 8 REV 02 740-011613 AM1033SH2MQ SFP-SX
Xcvr 9 REV 01 740-031851 AM1041SU1WW SFP-SX
...
There is one 10-Gigabit Ethernet MIC (MIC-3D-4XGE-XFP) installed into the MPC, MIC 0 (top slot), and
one Gigabit Ethernet MIC (MIC-3D-20GE-SFP) installed into the MPC, (MIC 1) (bottom slot). Each MIC is
logically divided into two PICs in the CLI.
The port numbers on the MICs correspond to the port number in the interface. See the MX Series Interface
Module Reference for more information on specific MICs.
Figure 34 on page 89 shows how the interfaces correspond to the ports on the MIC.
