CHAPTER 3
Cable and Rack Management
IN THIS CHAPTER
MX2020 Cable Management Description | 37
MX2020 Rack-Mounting Hardware | 42
MX2020 Cable Management Description
IN THIS SECTION
Standard Cable Management System | 37
Extended Cable Management System | 40
The MX2020 consists of a standard or extended cable management system.
Standard Cable Management System
The standard cable management system consists of the following components:
•
Upper cable manager—MX2000-CBL-TOP-S
•
Middle cable manager and air filter—MX2000-CBL-MID-S
•
Lower cable manager—MX2000-CBL-BTM-S
•
DC cable manager—MX2020-DC-CBL-MGR-S
The upper cable manager, (see Figure 14 on page 38) is located just below the craft interface, has a
removable cover that is secured by two captive screws with access to rows used for routing and securing
the cables away from the front of the Modular Port Concentrators (MPCs), and Modular Interface Cards
(MICs). The lower cable manager (see Figure 14 on page 38) is located just below the bottom line card
cage, has a removable cover that is secured by two captive screws with access to rows used for routing
and securing the cables away from the front of the MPCs, and MICs, (see Figure 15 on page 39).
37
