Figure 167: Removing a Three-Phase Delta AC Power Distribution Module (MX2008 Router)
NOTE: Each PDM slot not occupied by a AC PDM must be covered by a PDM blank panel.
SEE ALSO
MX2000 Three-Phase Delta AC Power Distribution Module Description | 96
MX2000 Three-Phase Delta AC Power Distribution Module Electrical Specifications | 184
Installing an MX2000 Router Three-Phase Delta AC Power Distribution Module
Before you install a three-phase delta AC power distribution module (PDM), be aware of the following:
WARNING: Before performing AC power procedures, disconnect all power sources.
To ensure that all power is off, locate the circuit breaker on the panel board that
services the AC circuit, switch the circuit breaker to the off position, and tape the
switch handle of the circuit breaker in the off position.
365
