Table 54: QSFP+ and QSFP28 Network Port Connector Pinout Information (continued)
SignalPin
RX2p22
GND23
RX4n24
RX4p25
GND26
ModPrsL27
IntL28
VccTx29
Vcc130
Reserved31
GND32
TX3p33
TX3n34
GND35
TX1p36
TX1n37
GND38
