Table 82: Parts List for a Fully Configured MX2020 Router (continued)
QuantityComponent
Up to 20ADCs
Up to 40MICs
Up to 8SFBs
1 or 2Combed Control Board with Routing Engines (CB-REs)
Up to 4Power distribution modules (PDMs)
Up to 18Power supply modules (PSMs)
4Fan trays
1Air baffle (optional)
2PSM air filter
1Air filter (lower)
1Standard upper cable manager
1Middle cable manager and air filter
1Standard lower cable manager
4Standard DC cable manager
1Extended upper cable manager (optional)
1Extended lower cable manager (optional)
4Extended DC cable manager (optional)
1Quick start installation instructions
One blank panel for each slot not
occupied by a component.
Blank panels for slots without components installed
233
