Table 84: Mounting Hole Locations for Installing the Four-Post Mounting Shelf (continued)
Distance Above U DivisionHole
1.50 in. (3.8 cm)3
0.88 in. (2.2 cm)2
0.25 in. (0.6 cm)1
Table 85: Mounting Hole Locations for Installing a MX2020 Chassis in a Four-Post Rack or Cabinet
Distance Above U DivisionHole
64.5 in. (163.8 cm)111
59.25 in (150.5 cm)102
54 in (127.2 cm)93
48.75 in (123.8 cm)84
43.5 in (110.5 cm)75
38.25 in (97.15 cm)66
33 in (83.8 cm)57
27.75 in (70.5 cm)48
22.5 in. (57.1 cm)39
17.25 in. (43.8 cm)30
14.25 in (36.2 cm)25
6.75 in. (17.1cm)12
3.75 in (9.5 cm)7
The holes in the front-mounting flanges are space at 3 U (5.25 in. (13.3 cm)).
